YQ-WIRE ROPE DRYER MACHINE
YUEQUN
Our factory advantage：
1. Established in 1994, with rich industry experienceWire Rope Dryer Machine for Veneer Drying Line
The Wire Rope Dryer Machine is an advanced veneer drying equipment designed for high-efficiency and uniform drying of wood veneers in plywood production. Utilizing a wire rope conveyor system, it ensures smooth veneer movement, consistent drying quality, and reduced labor costs.
This machine is widely used in core veneer and face veneer drying processes. With options for steam, thermal oil, or biomass heating, it is suitable for a variety of production capacities.
Key Features:
Stable wire rope conveyor system for smooth veneer transport
High thermal efficiency with uniform temperature distribution
Adjustable drying speed to match different veneer thicknesses
Energy-saving design with insulated chambers
Available in multi-deck models for large-scale production
Easy maintenance with modular spare parts
Applications:
Core veneer drying
Face veneer drying
Plywood and LVL production lines
Optional Configurations:
Steam, thermal oil, or biomass heating
PLC control system for automatic operation
Multi-layer drying chambers
| plywood roller dryer machine | |
| Working width | 2700mm |
| Working layers | 3 |
| Length of heating section | 13×2000mm=26000mm |
| Length of cooling section | 1×2000=2000mm |
| Total power | 172.5kw |
| Transport motor | 7.5kw×3=22.5kw |
| Heating motor | 11kw×13=143kw |
| Cooling motor | 3kw＋4kw=7kw |
| Overall dimension(L*W*H) | 33000×5200×4010mm |
| Total weight | 98tons |
